Heavy Duty Gas Line Regulators
LC856 Series
The LC856 Series Heavy Duty Gas Line Regulator is designed for final line pressure regulation and suitable for high flow gas distribution systems.
Features
• Single-stage construction
• Bonnet and body are made of forged stainless steel
• Operating temperature: -320 ~ 140ºF (-196 ~ 60ºC)
• Integrated diaphragm configuration ensures no-leak seal
• Internal filter
• Cleaned for oxygen service per CGA 4.1
Model Number | Maximum Inlet Pressure psi (bar) | Maximum Delivery Pressure psi (bar) | Inlet Connection | Outlet Connection |
LC856-50 | 435 (30) | 50 (3.5) | G 1" | G 1" |
| LC856-125 | 435 (30) | 123 (8.5) | G 1" | G 1" |
| LC856-200 | 435 (30) | 203 (14) | G 1" | G 1" |
