882VR Series

Continuous Suction Regulators

The 882VR Series Continuous-only Suction Regulators are light-weight, portable, and rugged. It is available in four vacuum ranges: 0-160, 0-200, 0-300, and 0-760 mmHg. This regulator features three modes of regulation: REG (regulated vacuum), OFF (no vacuum), and FULL (full, unregulated vacuum). The REG mode has a pressure relief set at 20% above the maximum gauge range for additional safety. The face cover is made of ABS for long durability. A variety of inlet and outlet fittings are available to cover a wide range of customer needs. Gauges are dual scale (mmHg/kPa) and clockwise, but is also available in ISO styles (counter-clockwise).

Product Inquiry

Ordering Info

SeriesVacuum RangeGaugeVacuum ConnectorSuction Connector
882VR160: 0~160 mmHg
200: 0~200 mmHg
(only for clockwise)
300: 0~300 mmHg
760: 0~760 mmHg
None: Clockwise
E: Counter-Clockwise
D: Digital Gauge
00: No Adapter, 1/8” NPT (F)
OH: Ohmeda® adapter (male)
DH: DISS Handwheel adapter (male)
DS: DISS hex adapter (male)
CH: Chemetron® adapter (male)
PB: Puritan-Bennett® adapter (male)
FS: French (NF S 90-116) adapter (male)
GS: German (DIN 13260-2) adapter (male)
BS: British (BS5682-1998) adapter (male)
JIS: Japanese Style adapter (male)
SIS: Australian (AS2896) adapter (male)
A: No Adapter, 1/8” NPT (F)
T: Suction Trap Assembly
(Complete)
B: Trap Fitting Only (No Trap)
C: DISS Male Vacuum
D: Tubing Nipple
(5/16” Hose Barb)



Specifications

• 2-1/2" Diameter Gauge
• Dual scale mmHg and kPa
• Glow in the dark gauge
• 3 Modes: REG/OFF/FULL

Dimensions

Dimensions without adapters or fittings
• Height - 6.3" (160 mm)
• Width - 3.15" (80 mm)
• Depth - 3.94" (100 mm)
• Weight - 14 oz. (0.40 kg)

Materials

Face Cover (body) - ABS Plastic

Restrictions

Caution SignWARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
